| Status | Active | Category | wire connector |
| Series | L 200012 Serise | Description | 2.0mm L200012 series automotive connector |
| Application | automotive connector | Component Type | Strip Connector |
| Product Name | 13065S-2-28A black plastic casing | Linsine Code | BCP13065S-0004 |
| Current - Maximum per Contact | 3.0A | Voltage - Maximum | 50V |
| Circuits (Loaded) | 28.32.40 | Circuits (maximum) | 40 |
| Color - Resin | Natural | Flammability | UL94V-0 |
| Lock to Mating Part | No | Material - Metal | Phosphor bronze |
| Material - Plating Mating | Tin | Material - Plating Termination | Tin |
| Number of Rows | 2 | Net Weight | 2.23/g |
| Packaging Type | Carton | Pitch - Mating Interface | 2.0mm |
| Applicable wires | AWG26#~22# | emperature range | -25°C~85°C |
Product Test Report
Q: Is OEM available?
A: Yes, OEM and customization are available. Also, we can provide label printing service.
Q: Are samples available?
A: Free samples are available while freight is chargeable.
Q: What is your payment terms?
A: T/T,L/C,D/A,D/P,Paypal for different circumstances.
Q: What's your delivery way?
A: Express delivery, air shipping, sea shipping are available for your request.
Q: What's your delivery time?
A: Usual delivery time is 5-10days after recieving the advance payment; For the customized product, 15-30 days after receiving the advance payment.
