| Status | Active | Category | Wire connector |
| Series | L250085 Series | Description | Single-row 2.5mm pitch Wire connector Appliance connector |
| Application | Appliance connector | Component Type | Strip Connector |
| Product Name | LX2517-4Y White High Flame Retardant / LX | Linsine Code | L250085-A04P-AW |
| Current - Maximum per Contact | 3.0A | Voltage - Maximum | 250V |
| Circuits (Loaded) | 4.5.6.7 | Circuits (maximum) | 7 |
| Color - Resin | Natural | Flammability | UL94V-0 |
| Lock to Mating Part | No | Material - Metal | Brass/Phosphor bronze |
| Material - Plating Mating | Tin | Material - Plating Termination | Tin |
| Number of Rows | 1 | Net Weight | 0.0448 |
| Packaging Type | Carton | Pitch - Mating Interface | 2.5mm |
| Applicable wires | AWG26#~22# | emperature range | -25°C~85°C |
Product Test Report
